LAM1432 350W Two-Way Passive Array Full Range Speaker

Features

● A compact loudspeaker system featuring an integrated processor (DSP) and line array technology.
● 10”MF×1, 1.4”HF×2
● Frequency Response:65Hz-18kHz
● Small in size, beautiful in shape, equipped with a special flight case, with strong mobility.
● With integrated design and installation, it is easy to use.
● Adopt wear-resistant surface treatment, with all-aluminum hanging parts.
● The system is suitable for small mobile performances, stadiums, theatres, bars, banquet halls and other places.

Contact now Leave message

Introduction
Specification

The LAM1432 is a compact passive speaker system featuring a two-way design. It comprises of two tweeters with a 36mm voice coil diameter and a 10" woofer, creating a powerful combination that delivers exceptional sound pressure and volume levels. To ensure optimal performance, the woofer is equipped with a specially designed intermediate frequency phase plug that minimizes interference and enhances the directional projection of mid-range frequencies. Additionally, the tweeter is combined with a plane wave transducer to produce a consistent and uniform sound wavefront.

Model	LAM1432
Unit Structure	10”MF×1, 1.4”HF×2
Frequency Response	65 Hz – 18 kHz
Sensitivity	MF: 96±2dB / HF: 104±2dB
MAX. SPL.	MF: 120±2dB / HF: 126±2dB
Continuous Power (AES)	MF: 350W / HF:120W
Rated Impedance	MF: 4Ω / HF: 16Ω
Single Speaker Directivity (H×V)	100°×10°
Color	Black
Dimensions (W×H×D)	500mm×296mm×342mm
Weight	20kg
